Rubber Compounds for Electronics & Electrical Safety
Electronics demand materials that control conductivity, protect components, and perform reliably under changing temperatures and pressures. Rubber compounds play a critical role in this sector, bridging insulation, conductivity, sealing, EMI/RFI shielding, heat dissipation, and electrostatic control. With the right formulation, rubber becomes more than a barrier — it becomes part of the electrical protection system itself.
Manufacturers rely on electrically conductive rubber and thermally optimized elastomers—supported by advanced industrial rubber mixing processes—to move current where needed, block interference, ground components, dissipate static electricity, and maintain a sealed environment. From low-amperage conductive gaskets to EMI-shielding materials filled with metal particles, these compounds are engineered to solve electrical and electronic challenges traditional materials can’t.
Material Performance in Demanding Electronics Applications
Rubber compounds must maintain stable performance in environments exposed to heat, compression, vibration, high-frequency signals, and long-term aging. Engineering teams often require:
- Consistent conductivity for grounding and ESD protection
- EMI/RFI shielding for enclosures and communication systems
- Thermal stability to manage heat buildup or prevent overheating
- Reliable sealing to protect sensitive components from moisture or contaminants
- Chemical or fuel resistance for aerospace and defense electronics
- Long-term durability without cracking, shrinking, or losing performance
Silicones, fluoroelastomers, EPDM, and specialty-filled compounds are common choices. Carbon-filled, metal-filled, or graphite-filled rubber can be precision-engineered to meet conductivity and shielding requirements without sacrificing flexibility or sealing integrity.
Where Electrically Conductive Rubber Is Used
Electrically conductive rubber combines electrical performance with the sealing and flexibility of elastomers. Conductivity is achieved by dispersing conductive fillers—such as nickel-graphite, silver-plated aluminum, or graphite—throughout the polymer structure.
Common functions:
- Low-amperage conduction
- EMI/RFI shielding
- Grounding and static dissipation
- Electrical interconnect pads
- Shielded enclosure gaskets
- Electrical contacts and keypad switches
Conductive silicone rubber offers excellent UV stability, high temperature resistance, and long-term resiliency. It can be molded, die-cut, or fabricated into gaskets, O-rings, sheets, strips, and custom profiles.
Ready to get started?
Let’s talk about your project and performance needs.
* Required
* Required
Thermal Conductivity of Rubber Compounds
Unlike metal, rubber is naturally insulating—but the thermal behavior of rubber is especially important in electronics, where heat buildup can damage components. Thermal conductivity varies significantly by polymer and filler system:
| Rubber Type | Thermal Conductivity (W/mK @ 25°C) |
|---|---|
| Silicone Rubber | ~0.14 |
| Neoprene | ~0.19 |
| Nitrile (NBR) | ~0.24 |
| Polyurethane Rubber | ~0.29 |
| Fluoroelastomers | ~0.19 – 0.30 |
| Silicone – Glass Filled | ~0.35 |
| Silicone for Thermal Management (special grades) | 0.63 – 2.51 |
Thermal performance can shift under pressure and heat as elastomers compress, changing total thermal resistance. For electronics that heat-cycle, real-world operating thickness matters as much as the base conductivity.
